BVM PNP F-16  1:5 Scale





PRICE $10,379.00
includes freight shipped within the USA

Includes NEW BVM branded Servos

What is Go Fly Gold?

First shown at Florida Jets 2016, this new BVM offering was honored with a "Special Recognition Award" for a new product. This is a "Go Fly" jet with lots of features similar to the BVM, 1/6th F-16, Cougar and YAK-130.

It's light weight is one of those special features.

Dustin accomplished the airshow flight at Florida Jets and Greg Arnette has since logged dozens of flights on this sample to help BVM get it "right".



Specs:
Length 120"  Wingspan  80"
Weight: 46 Lbs + fuel
Power: 200 - 220 Newtons
Flight Time: 9+ minutes

Special Features Installed

  • Super Scale Undercarriage

  • Raised Panel Details

  • Smoke System

  • BVM Hi-Flow Fuel System

  • Afterburner Ring

  • Sidewinder Tip Missiles

  • Servos (all)

  • Central Control Unit for landing gear, doors, wheel brakes, and light systems

  • BVM Air Fill Valve

  • Scale Cockpit

  • Tailpipe

  • Fuse (shipped one piece, saves assembly time)

BVM Servos Now Installed in   Models

BVM servos (32kg and 42kg) are now installed in our F-16 1:5 scale model.

The NEW BVM Servos offer a higher resolution than the previously installed servo's.

The 32kg & 42kg are HV, Digital, and Brushless.

Made by a well known manufacture in Taiwan.

Only available with a model purchase. Not available for individual sale.

  BLS 320 Specifications:
Torque @ 7.4v - 32.0kg/444.4oz-in
Speed @ 7.4v - 0.12 sec/60 deg
Refresh Rate: 333Hz
Motor Type: Brushless
Resolution (4096)

  BLS 420 Specifications:
Torque @ 7.4v - 42.0kg/583.3oz-in
Speed @ 7.4v - 0.13 sec/60 deg
Refresh Rate: 333Hz
Motor Type: Brushless
Resolution (4096)


Controls QTY Servo Type
Steering 1 32kg

Aileron 2 32kg

Flap

Rudder 1 32kg

Elevator 2 42kg

Canopy 1 42kg





BVM Instruction Manual

A 48 page, photo enhanced manual, guides you through the necessary steps to get the Falcon airworthy. Templates for setting control travels and C.G. placement along with a suggested first flight profile are provided to ensure your success.



PRICE $10,379.00
includes freight shipped within the USA

What is Go Fly Gold?



F-16 1:5 Scale

The second BVM prototype flew 10 April 2016.


Kirby Smith, Greg Arnette, and Dustin Buescher double checked all of the systems at the field.




Dustin Buescher did the honors for the first flights and fine adjusted some trim and gyro settings.

Dustin won 1st Place at Top Gun 2016 in the new Scale X Class with this model.



#3 prototype May 2016 at "First In Flight"

Having 3 prototypes has allowed BVM to improve a few parts and create a typical BVM Assembly and Flight Manual for this new product.



Items Needed To Complete:
Available from BVM:

● 200-220N engine of your choice.

● BVM Hi-Flow U.A.T. (#TA-SR-1001)

● Spektrum 12120 Power Safe Receiver (#VJ-SPMAR12120)

● Spektrum X-Plus 8 Expansion Module (#VJ-SPMXP8000)

● (2) 7.4v Batteries 4500 mAh Magnum Ion (#VU-7456EXB-HC-EC3)

● Bavarian Demon Aero Cortex Gyro (#V-DA-BD-Cortex)

● Cortex USB PC Adapter (#V-DA-BD-PC Adapter)



Recommended Accessories:

Pulse Ultra Batteries

You may have some of these products in your shop, but if not, refer to this list.

#V-WB 15 JET PILOT     15" Jet Pilot Modern   $139.99

● BVM Hi-Flow Over Flow Tank (#TA-SR-1013)

● Spektrum Flight Log (#SPM9540)

● #2 x 3/16 Button Head SMS Package (BVM# 5625)

● BVM “O Clips” (#PA-SR-0026)

● BVM Velcro Package (#PA-SR-0081)

● Safety Wire (BVM# 2800)

● (2)12” battery extension wire (#VJ-SPMEXEC312)

● BVM Over Flow Tank (for Smoke System) (BVM# 6047)

● Flush Mount Vent Fitting (#PS-SP-0301)
       (For Over Flow Tank)

● Flush Mount Vent Plug (#PS-SP-0302)
       (For Over Flow Tank)

● HD Y Harness (#VJ-JRPA135)

● Male/Male Lead (#VJ-JRPA050)

List of Adhesives/Lubricants:

Details:

click on images to enlarge

  This view of the landing gear and doors on the big F-16 shows the attention to scale details and function.


The canopy is servo or hand operated.

  The cockpit deck lifts out in one piece giving access to all electronic control and read-out devices.

 Labels on the pneumatic/mechanical gear and door selector valves are handy. A special Central Control Unit instruction manual is provided.







Color Schemes:


#K9200-20       Dark Falcon


#K9200-18        Greek



#K9200-14        Texas Retro

#K9200-13        Singapore Knights



#K9200-10        Indiana ANG

#K9200-12        Alaska



# K9200-01      General Dynamics

# K9200-00     2-3 Tone Grey


# K9200-00-AR     2-3 Tone Grey Arkansas

# K9200-02       Navy Aggressor


# K9200-04     ThunderBird

#K9200-06        Edwards Chase



#K9200-07        Texas ANG

#K9200-08        Minute Men


#K9200-05        Israel





F-16 1:5 Scale Addendums

Airframe Directive (A.D.)
And other helpful notes

Canopy Locking Addendum
(11/2017)

Check that the servo arm does not stop short of full travel because it is touching the aft frame work. If it does, use a dremel carbide cutter to make a notch as shown. After the notch is made, you can see that the cable operated locking pins can move a bit further forward. This improves the locking pin engagement.




Canopy Retention
(10/2017)

Accumulation of manufacturing tolerances can lead to slight variances in the end products.



Cockpit Tub

Before Modification   After Modification

Trim off the small tabs at forward end of plastic cockpit tub. This will ensure that the tub does not slide aft and disengage the retention hooks.

See other addendums relative to the canopy operation.


Canopy
(02/2017)

Apply Z-42 (blue thread locker) to the exposed end of these 2 bolts. This precaution will keep the bolts from backing out of the aluminum fittings as the canopy is operated open and close.




Canopy
(10/2016)

Important Note:  Do not rely on the servo operated latching mechanism to fully hold the Canopy down and locked. Always manually push down on the front of the Canopy Hatch as it lowers to insure that the 2 locking pins are fully engaged.


U.A.T. Check
(10/2016)

Inspect the U.A.T. to insure that there is clearance between the Main Wheel in the up position and the U.A.T.
It may be necessary to shim the U.A.T. up about 1/4”.




Customer Hotshots
click on images to enlarge





Brian Blois with his F-16 1:5 scale. This model is powered by an EvoJet 220neo which flies the airplane perfectly while keeping the airframe as light as possible. Guided by SpektrumRC equipment, DX20, AS300 AS3X flight stabilization, AR20310T Powersafe RX and Smart RX and Turbine batteries.
